表面贴装零部件

为您的 Fuzion®、Genesis™、AdvantisV™、Advantis™ 或 GSM™ 平台购置环球仪器正品零部件。

吸嘴

快捷链接

隐藏式切换

您的内容放在这里。在行内或在模块内容设置中编辑或删除此文本。您还可以在模块“设计”设置中对这些内容的各个方面进行样式设计,甚至可以在模块“高级”设置中对这些文字应用自定义 CSS(层叠样式表)。

30 轴针贴装头吸嘴



Part Number
Nozzle Kits
Description
Part Number
Description
FZ30 Steel/Ceramic Nozzle Kit
This kit includes steel and ceramic nozzles to handle 0402-1206 components.
This kit contains a quantity (30) of the following nozzles:
51305433 0402 Ceramic Blade Nozzle (3030)
51305434 0603 Ceramic Blade Nozzle (3040)
51305411 0805 Steel Nozzle (3440)
51305412 1206 Steel Nozzle (3450)
Part Number
Description
FZ30 Small Part Nozzle Kit
This kit includes nozzles that can handle 0402-1206 components and is comprised of a blend of compliant and ceramic tip nozzles.
This kit contains a quantity (30) of the following nozzles:
51305433 0402 Ceramic Blade Nozzle (3030)
51305434 0603 Ceramic Blade Nozzle (3040)
51305422 0805 Compliant Nozzle (3540)
51305423 1206 Compliant Nozzle (3550)
Part Number
Description
FZ30 Compliant Starter Nozzle Kit
This kit includes nozzles for 0402-1206 Chips, 042 and 083 Melfs and .124, .234 & .340 Cups.
This kit contains a quantity of the following nozzles:
51305434 0603 Ceramic Blade Nozzle (3040) qty 10
51305422 0805 Compliant Nozzle (3540) qty 10
51305423 1206 Compliant Nozzle (3550) qty 10
51305415 .125 Compliant Cup Nozzle (3220) qty 1
51305428 340 Compliant Cup Nozzle (3260) qty 1
51305417 .234, Comp Cup, HSC (3240)-CN qty 1
51305409 042MF Melf Nozzle (3320) qty 1
51305410 083MF Melf Nozzle (3340) qty 1
51305433 0402 Ceramic Blade Nozzle (3030) qty 10
Part Number
Description
FZ30 Head Top Sellers Nozzle Kit
This kit contains our most popular nozzles for the FZ30 head.
This kit contains a quantity of the following nozzles:
51305434 0603 Ceramic Blade Nozzle (3040) qty 10
51305415 .125 Compliant Cup Nozzle (3220) qty 10
51305417 .234, Comp Cup, HSC (3240)-CN qty 5
51305411 0805 Steel Nozzle (3440) qty 10
51305412 1206 Steel Nozzle (3450) qty 10
51305414 0201 Ceramic Blade Nozzle (3021) qty 5
51305423 1206 Compliant Nozzle (3550) qty 10
51305422 0805 Compliant Nozzle (3540) qty 10
51305433 0402 Ceramic Blade Nozzle (3030) qty 10
Part Number
Description
FZ30 Long Life Ceramic Nozzle Kit
This kit includes a complete line of long-life ceramic nozzles to handle 0201-0603 chips.
This kit contains a quantity of the following nozzles:
51305434 0603 Ceramic Blade Nozzle (3040) qty 30
51305414 0201 Ceramic Blade Nozzle (3021) qty 30
51305433 0402 Ceramic Blade Nozzle (3030) qty 30
51305435 NOZZ HSC, (3011)MP-01X005-CX qty 5
Part Number
Standard Nozzles
Description
Part Number
Description
0201 Ceramic Blade Nozzle (3021) – Nozzle is designed to place *0201 components
Part Number
Description
0402 Ceramic Blade Nozzle (3030) – Nozzle is designed to place 0402 components
Part Number
Description
0603 Steel Nozzle (3430) – Nozzle is designed to place .0603 components
Part Number
Description
0805 Steel Nozzle (3440) – Nozzle is designed to place .0805 components
Part Number
Description
1206 Steel Nozzle (3450) – Nozzle is designed to place 1206C, 1206R, 1210C, 1210R components
Part Number
Description
042MF Melf Nozzle (3320) – Nozzle is designed to place MELFS - 2.0x1.3 components
Part Number
Description
083MF Melf Nozzle (3340) – Nozzle can be used to place MELF- 3.4x1.4 to MELF - 9.3x2.6 components
Part Number
Description
0805 Compliant Nozzle (3540) 0150 – Nozzle is designed to place 805R and 805C components
Part Number
Description
1206 Compliant Nozzle (3550) – Nozzle is designed to place 1206C, 1206R, 1210C, 1210R components
Part Number
Description
.125 Compliant Cup Nozzle (3220) – Nozzle is designed to place 1812, PLCC18, SOIC8, SOIC14 components
Part Number
Description
.234 Compliant Cup Nozzle (3240) – Nozzle is designed to place SOIC18, SOJ42, APCAP 10 x 10 components
Part Number
Description
.340 Compliant Cup Nozzle (3260) – Nozzle is designed to place PLCC100, PLCC32, PLCC84, QFP100, QFP160, SOIC10 components
Part Number
Replaceable-Tip Nozzles
Description
Part Number
Description
Lightning 3530 (603 Compliant)
Part Number
Description
0603 Replaceable Tip
Part Number
Short Nozzles
Description
Part Number
Description
Short Lightning 4220 (.125s)
Part Number
Description
Short Lightning 4240 (.234s)
Part Number
Description
Short Lightning 4260 (.340s)
Part Number
Specialty Nozzles
Description
Part Number
Description
Lightning T004 (0603 - 1206 Combo)
Part Number
Description
Lightning E-Cap Nozzle 3.1 - 3.1mm Dia
Part Number
Description
Lightning E-Cap Nozzle 3.9 - 3.9mm Dia
Part Number
Description
Lightning E-Cap Nozzle 4.9 - 6.2mm Dia
隐藏式切换

您的内容放在这里。在行内或在模块内容设置中编辑或删除此文本。您还可以在模块“设计”设置中对这些内容的各个方面进行样式设计,甚至可以在模块“高级”设置中对这些文字应用自定义 CSS(层叠样式表)。

7 轴针贴装头吸嘴



Part Number
Nozzle Kits
Description
Part Number
Description
FZ7 Top Sellers Nozzle Kit
This kit includes our most popular nozzles for the FZ7 head.
A quantity of each of the following nozzles are included:
51305324 .234 Compliant Cup Nozzle (1240) qty 4
51305323 .125 Compliant Cup Nozzle (1220) qty 4
51305329 NOZZ FJC, IC-340-CN qty 4
51305325 10MPF Multi-Port Nozzle (1140) qty 3
51305305 08MPF Multi-Port Nozzle (1120) qty 2
51305310 0603 Ceramic Blade Nozzle (1060) qty 2
51305309 0402 Ceramic Blade Nozzle (1040) qty 2V51305306 083MF Melf Nozzle (1340) qty 1
51305307 042MF Melf Nozzle (1320) qty 1
Part Number
Description
FZ7 Large Part Nozzle Kit
This kit includes a complete line of cup nozzles ideal for placing larger parts.
A quantity of each of the following nozzles are included:
51305324 .234 Compliant Cup Nozzle (1240) qty 7
51305323 .125 Compliant Cup Nozzle (1220) qty 7
51305329 NOZZ FJC, IC-340-CN qty
51305313 .360 Compliant Cup Nozzle (1280) qty 2
Part Number
Description
FZ7 Long-Life Ceramic Nozzle Kit
This kit contains includes a complete line of long-life ceramic nozzles to handle 0201 - 1206 chips and more.
A quantity of each of the following nozzles are included:
51305305 08MPF Multi-Port Nozzle (1120) qty 3
51305309 0402 Ceramic Blade Nozzle (1040) qty 2
51305310 0603 Ceramic Blade Nozzle (1060) qty 3
51305325 10MPF Multi-Port Nozzle (1140) qty 3
51305308 0201 Ceramic Blade Nozzle (1020) qty 1
Part Number
Standard Nozzles – FlexJet2 / FlexJet3 / Inline7
Description
Part Number
Description
042MF Melf Nozzle (1320) – Can be used to place smaller MELFS, coils and cylindrical diodes. For approximate component diameter of .042" (1.07mm)
Part Number
Description
083MF Melf Nozzle (1340) – Can be used to place Larger MELFS, coils & cylindrical diodes
Part Number
Description
0201 Ceramic Blade Nozzle (1020) – Can be used to place 0201 Chips in .010 - .015 "placement density"
Part Number
Description
0402 Ceramic Blade Nozzle (1040) – Can be used to place 0402 Chips in .010-.015 "placement density
Part Number
Description
08MPF Multi-Port Nozzle (1120) – Can be used to place 805, 1206 Tant Caps, SOT-23
Part Number
Description
0603 Ceramic Blade Nozzle (1060 – Can be used to place 0603 chips in .010-.015 "placement density"
Part Number
Description
10MPF Multi-Port Nozzle (1140) – Can be used to place 0805- SOIC 8 components
Part Number
Description
.234 Compliant Cup Nozzle (1240) – Can be used to place SOIC 14 - PLCC 52 components
Part Number
Description
.340 Compliant Cup Nozzle (1260) – Can be used to place SOIC 20 - QFP 304 components
Part Number
Description
.360 Compliant Cup Nozzle (1280) – Can be used to place PLCC 32 - QFP 304 components
Part Number
Replaceable-Tip Nozzles – FlexJet2 / FlexJet3 / Inline7
Description
Part Number
Description
FJ2/3 Replace Tip Noz w/3.5mm, 2mm tips
Part Number
Description
FJ2/3 Replace Tip Noz w/5, 6, 8mm tips
Part Number
Description
0603 Compliant Tip Nozzle
Part Number
Description
0603 Replaceable Tip
Part Number
Description
Replaceable Tip, 2mm
Part Number
Description
Replaceable Tip, 3.5mm
Part Number
Description
Replaceable Tip, 5mm
Part Number
Description
Replaceable Suction Cup Tip, 6mm
Part Number
Description
Replaceable Suction Cup Tip, 8mm
Part Number
Specialty Nozzles – FlexJet2 / FlexJet3 / Inline7
Description
Part Number
Description
FJ2/3 E-Cap Nozzle 3.1 - 6.25mm Dia
Part Number
Description
FJ2/3 Nozzle Long Life (234F compliant)
Part Number
Description
FJ2/3 Nozzle Tip Assy, CAL/FID
Part Number
Description
FJ2/3 Nozzle 058C
Part Number
Description
FJ2/3 Nozzle 072C
Part Number
Description
FJ2/3 Nozzle 160C
Part Number
Description
FJ2/3 Nozzle 120F
Part Number
Description
0805 Compliant Tip Nozzle
Part Number
Description
FJ2/3 Ribbon Connector
隐藏式切换

您的内容放在这里。在行内或在模块内容设置中编辑或删除此文本。您还可以在模块“设计”设置中对这些内容的各个方面进行样式设计,甚至可以在模块“高级”设置中对这些文字应用自定义 CSS(层叠样式表)。

4 轴针贴装头吸嘴



Part Number
Nozzle Kits
Description
Part Number
Description
FZ4 Top Sellers Nozzle Kit
This kit includes a blend of our most popular nozzles for the FZ4 head.
A quantity of each of the following nozzles are included:
51305118 NOZZ FL, 1C-234F-CN qty 4
51305105 10MPF Multi-Port Nozzle (10MPF) qty 4
51305120 NOZZ FL, IC-340F-CN qty 4
51305115 NOZZ FL, 1C-125F-CN qty 4
51305106 08MPF Multi-Port Nozzle (8MPF) qty 4
51305104 .120 Compliant Cup Nozzle (120F) qty 3
51305110 .160 Compliant Pipe Nozzle (160F) qty 2
49960202 NOZZ FL, 1C-125M.CUP/RT-CN qty 2
Part Number
Description
FZ4 Large Part Nozzle Kit
This kit includes a complete line of cup nozzles for the FZ4 spindle head.
A quantity of each of the following nozzles are included:
51305118 NOZZ FL, 1C-234F-CN qty 4
51305120 NOZZ FL, IC-340F-CN qty 4
51305115 NOZZ FL, 1C-125F-CN qty 4
51305104 .120 Compliant Cup Nozzle (120F) qty 3
51305110 .160 Compliant Pipe Nozzle (160F) qty 3
45466917 .360 Compliant Cup Nozzle (360F) qty 2
Part Number
Standard Flex / C4 / Inline4 Nozzles
Description
Part Number
Description
.042 Melf Nozzle (042MF) – Nozzle is designed to place smaller MELFS, coils and cylindrical diodes
Part Number
Description
PE/IL4 Nozzle 083MF Melf
Part Number
Description
PE/IL4 Nozzle 08MPF Mini Multi-Port
Part Number
Description
PE/IL4 Nozzle 10MPF Large Multi-Port
Part Number
Description
.234 Compliant Cup Nozzle (234F)
Part Number
Description
PE/IL4 Nozzle 340F Molded
Part Number
Description
.120 Compliant Cup Nozzle (120F)
Part Number
Description
PE/IL4 Nozzle 125F Compliant Tip
Part Number
Description
PE/IL4 Nozzle 160F Compliant Tip
Part Number
Description
PE/IL4 Nozzle 360F Compliant Tip
Part Number
Description
PE/IL4 Nozzle 460XF Suction Cup Tip
Part Number
Description
PE/IL4 Nozzle 10MF NON ESD
Part Number
Replaceable-Tip Flex / C4 / Inline4 Nozzles
Description
Part Number
Description
IL4 Rep. Tip Noz 125 w/2 & 3.5mm Tips
Part Number
Description
IL4 Rep. Tip Noz 234 w/5, 6 & 8mm Tips
Part Number
Description
Replaceable Tip, 2mm
Part Number
Description
Replaceable Tip, 3.5mm
Part Number
Description
Replaceable Tip, 5mm
Part Number
Description
Part Number
Description
Replaceable Suction Cup Tip, 6mm
Part Number
Description
8mm/.315 Replaceable Nozzle Tip
Part Number
Specialty Flex / C4 / Inline4 Nozzles
Description
Part Number
Description
Flex/C4/IL4 E-Cap Nozzle
Part Number
Description
Flex Ribbon Connector
Part Number
Grippers
Description
Part Number
Description
Adjustable Gripper Assembly FJ/IL7
Part Number
Description
Adjustable Gripper Assembly

送料器

隐藏式切换

您的内容放在这里。在行内或在模块内容设置中编辑或删除此文本。您还可以在模块“设计”设置中对这些内容的各个方面进行样式设计,甚至可以在模块“高级”设置中对这些文字应用自定义 CSS(层叠样式表)。

带式送料器



Part Number
ion Feeders
Description
Part Number
Description
8MM DL ION TAPE FEEDER
Part Number
Description
12MM SL ION TAPE FEEDER
Part Number
Description
16MM SL ION TAPE FEEDER
Part Number
ion Feeder Reel Holders
Description
Part Number
Description
8MM DL 7" ION DUAL REEL HOLDER
Part Number
Description
8MM DL 7-13" ION SINGLE REEL HOLDER
Part Number
Description
12/16MM SL 7-15" ION SINGLE REEL HOLDER
Part Number
Gold Feeders
Description
Part Number
Description
8MM HP GOLD PLUS SPLICEABLE TAPE FEEDER
Part Number
Description
8MM HP DUAL LANE-60 GOLD PLUS, 7" - 13"
Part Number
Description
8MM HIGH PERFORMANCE DL-60 GOLD PLUS
Part Number
Description
12MM HP GOLD PLUS SPLICEABLE TAPE FEEDER
Part Number
Description
16MM HP GOLD SPLICEABLE TAPE FEEDER
Part Number
Description
24MM HP GOLD SPLICEABLE TAPE FEEDER
Part Number
Description
32MM HP GOLD SPLICEABLE TAPE FEEDER
Part Number
Description
44MM HP GOLD SPLICEABLE TAPE FEEDER
Part Number
Description
56MM HP GOLD SPLICEABLE TAPE FEEDER
Part Number
Description
72MM HP GOLD SPLICEABLE TAPE FEEDER
Part Number
Description
88MM HP GOLD SPLICEABLE TAPE FEEDER
隐藏式切换

您的内容放在这里。在行内或在模块内容设置中编辑或删除此文本。您还可以在模块“设计”设置中对这些内容的各个方面进行样式设计,甚至可以在模块“高级”设置中对这些文字应用自定义 CSS(层叠样式表)。

定制送料器



Part Number
Description
FDR, 24MM&16MM/HP/CP/25MMDP/MOD/TW24MM
Details
16mm and 24mm High Performace Gold Feeder with 25MM Deep Pocket and pick point adjusted 24mm back
Part Number
Description
FDR, 32MM/HP/CP/25MMDP/MOD/TW24MM
Details
32mm High Performace Gold Feeder with 25MM Deep Pocket and pick point adjusted 24mm back
Part Number
Description
FDR, 44MM/HP/CS/25MMDP/MOD/TW24MM
Details
44mm High Performace Gold Feeder with 25MM Deep Pocket and pick point adjusted 24mm back
Part Number
Description
FDR,56MM-HP/CS/25MMDP/MOD/TW24MM
Details
56mm High Performace Gold Feeder with 25MM Deep Pocket and pick point adjusted 24mm back
Part Number
Description
FDR, 72MM-HP/CS/25MMDP/MOD/TW24MM
Details
72mm High Performace Gold Feeder with 25MM Deep Pocket and pick point adjusted 24mm back
Part Number
Description
16MM SL ION TAPE FEEDER 13MM DP
Details
16mm Ion feeder with 13mm Deep Pocket
隐藏式切换

您的内容放在这里。在行内或在模块内容设置中编辑或删除此文本。您还可以在模块“设计”设置中对这些内容的各个方面进行样式设计,甚至可以在模块“高级”设置中对这些文字应用自定义 CSS(层叠样式表)。

送料器套装



Part Number
Hardware kits - HIGH PERFORMANCE GOLD FEEDERS
Description
Part Number
Description
8mm Dual Lane Hardware Kit
Part Number
Description
8-88mm PrecisionPro (Green) Hardware Kit
Part Number
Description
8-32mm High Performance Gold Hardware Kit
Part Number
Hardware kits - HIGH PERFORMANCE GOLD FEEDERS
Description
Part Number
Description
RPK, 8-12mm Gold Feeder RPK
Part Number
Description
RPK, 8mm Dual Lane Gold
Part Number
Description
RPK, 16mm-32mm Gold Feeder
Part Number
Description
RPK, 44mm-88mm Gold Feeder
Part Number
Replacement Side Cover Kits - HIGH PERFORMANCE GOLD & GREEN FEEDERS
Description
Part Number
Description
KIT, SIDE COVERS, HIGH TEMPER, GOLD
Part Number
Description
KIT, SIDE COVERS, HIGH TEMPER, GREEN
Part Number
Pitch Conversion Kits - ION FEEDERS
Description
Part Number
Description
KIT, 16 TO 12MM CONV, ION SL TAPE FDR
Part Number
Description
KIT, 12 TO 16MM CONV, ION SL TAPE FDR
Part Number
Description
KIT, 12 OR 16MM CONV, ION SL TAPE FDR
Part Number
Description
KIT, 16 TO 12MM CONV, ION SL TAPE FDR
Part Number
Description
KIT, 12 TO 16MM CONV, ION SL TAPE FDR
Part Number
Description
KIT, 12 OR 16MM CONV, ION SL TAPE FDR
Part Number
Controller Replacement Kits - ION FEEDERS
Description
Part Number
Description
KIT, DL8 ION CTRL REPLACEMENT
Part Number
Description
KIT, SL12/16 ION CTRL REPLACEMENT

生产配件

隐藏式切换

您的内容放在这里。在行内或在模块内容设置中编辑或删除此文本。您还可以在模块“设计”设置中对这些内容的各个方面进行样式设计,甚至可以在模块“高级”设置中对这些文字应用自定义 CSS(层叠样式表)。

生产配件



Part Number
Feeder Banks & Baskets
Description
Details
Part Number
Description
ion Feeder Bank Assy, Removable
Details
ion Removable Feeder Bank Assembly. To be used on Fuzion platform machines only
Part Number
Description
Feeder Bank Assy, Removable - S2
Details
Series 2 / Advantis Removable Feeder Bank Assembly
Part Number
Description
XC - ion Feeder Bank Assy, Removable
Details
ion Removable Feeder Bank Assembly for use on Fuzion XC Machines only
Part Number
Description
Ion Feeder Basket Assembly
Details
This basket assembly will hold up to 27 reels(side-by-side) within a bank of feeders, which eliminates the need for multiple reel holders. This option includes 1 basket, cutter and scrap bin. *The purchase of additional dividers and reel holder pins is required.
Part Number
Description
ion Basket - Reels & Dividers
Details
This kit provides 18 dividers and associated reel holder pins to support a single ion basket assembly. 1 kit per basket assembly is recommended.
Part Number
Feeder Bank Peripherals
Description
Details
Part Number
Description
ion Feeder Bank Change Cart
Details
The rolling ion feeder bank change cart is used for removable feeder bank installation, removal, or transport. The feeder bank change cart also reduces changeover time by allowing the swap of up to 18 feeders at a time.
Part Number
Description
ion Feeder Transfer Cart Upgrade Kit
Details
The ion feeder upgrade kit allows older-style (Series 2) transfer carts to be upgraded for ion basket compatibility. 1 kit per cart is required.
Part Number
Description
Feeder Bank Storage Table
Details
The removable feeder bank storage table provides off-line storage for two feeder banks with or without feeders. The table can also be used for off-line bank setup to reduce job change time.
Part Number
Description
Feeder Transfer Cart
Details
Feeder Transfer Cart
Part Number
Feeder Management Peripherals
Description
Details
Part Number
Description
Feeder Storage Rack
Details
Reduces product changeover by providing feeder storage for tape track and/or tray feeders in one convenient location. Each cart holds up to 136 8mm single-lane feeders.
Part Number
Description
Single Feeder Index Station, Mach. Mount
Details
Machine Mounted Single Feeder Load Station (ion compatible): This station allows for fast feeder preparation at the machine and is mounted on a swing arm for easy sharing. This option includes ion specific features for feeder latching as well as reel management. This option can be used with either gold or ion feeders.
Part Number
Description
SINGLE FDR INDEX STATION, NARROW
Details
Part Number
Description
ion Feeder Offline Setup Station
Details
This ion compatible, CE-compliant setup station reduces production delays associated with feeder replenishment since feeders are easily prepared for full bank validation and setup offline. This feature increases platform utilization by allowing for feeder loading on the bank. The station can be used with both Gold and ion feeders.
Part Number
Description
Tape Scrap Bin
Details
A tape scrap bin on wheels which provides a means of collecting tape scrap during production. Up to four scrap bins may be positioned at the Platform machine, one for each bank. This option can not be used with 7-13" Dual Lane Feeders, or feeders baskets.
Part Number
Description
Low-Profile Tape Scrap Bin
Details
Low-Profile Tape Scrap Bin –
A low-profile tape scrap bin provides a means of collecting tape scrap during production. Due to the smaller size of this bin, it is compatible with all feeder types. Up to four bins may be positioned at the Platform machine, one for each bank.
Part Number
Description
Scrap Tape Cutter
Details
The scrap tape cutter is designed to cut off small pieces of reel tape and collect them in bin for ease of disposal. This cutter can accomodate two banks of tape for disposal, with a maximum of two cutters per machine. The unit is mounted on wheels to allow for easy changeover. Not compatible with feeder baskets.
Part Number
Description
Component Reject Station (42V)
Details
The Component Reject Station consists of a belt conveyor and an end mounted collection bin. The reject conveyor moves rejected components away from the placement head and puts them within safe reach of the operator. This allows for easy retrieval and inspection of the components without having to access the machine directly.
Part Number
Replacement Parts Kits
Description
Details
Part Number
Description
Fuzion - RPK Basic Kit
Details
A basic repair and maintenance parts kit for the Fuzion platform, which helps to minimize downtime. The kit includes a leveler assembly, timing belts and fuses.
Part Number
Description
30-Spindle Head Maintenance Kit
Details
A basic parts kit for the maintenance of the 30-Spindle Head spindles. The kit includes a theta motor assembly, o-rings, valves, seals cleaning wires, hardware and tools necessary to properly install.
Part Number
Description
Replacement Spindle Kit
Details
Replacement kit for head spindle assemblies. This kit includes five (5) additional spindle assemblies and a storage box. One kit per line is recommended.
Part Number
Description
RPK, Pneumatic Filter
Details
A maintenance parts kit for the Pneumatic Filter, which contains replacements for the machine's input air filters
Part Number
Description
RPK, Platform Lubrication Kit
Details
This kit includes the lubricants required for regular machine maintenance. Applicable for 30 and 7-Spindle platform machines only.
Part Number
Tools Kits
Description
Details
Part Number
Description
Platform Maintenance Tool Kit
Details
This kit includes the tools required to perform maintenance on the Platform machine. Kit includes the following:
- Machine zero fiducial fixture for establishing machine zero when necessary
- Grease gun
- Stator lubrication oil
- Grease gun attachments
- Cleaning cloth
One kit per site is recommended.
Part Number
Description
30-Spindle Head Maintenance and Tool Kit
Details
Maintenance on the 30-Spindle placement head. Kit includes:
- Vacuum test fixture
- Spacers for read and scanning head setup
- Hex drivers
- Retaining ring pliers
- Custom grease tips
One kit per site is recommended.
Part Number
Description
Nozzle Removal Tool
Details
The Nozzle Removal tool is used to quickly remove, clean and re-install up to 35 nozzles at once. This tool significantly reduces the time required to clean the nozzles and ensure that each are reinstalled in the correct location by allowing the operator to remove and secure each nozzle, clean in the ultrasonic bath, and return them to their original location. Two units are recommended to cover a complete cleaning cycle.
Part Number
Description
Nozzle Cleaning Wire Kit
Details
This kit consists of wires which can be used to clean the nozzle ports
Part Number
Description
Spindle Tester Assembly
Details
The spindle tester assembly aids in the maintenance and troubleshooting of head spindle assemblies to help quickly identify suspect components. It also minimizes production downtime and reduces maintenance costs.
Part Number
Description
Adjustable Board Support Kit
Details
The adjustable board support kit includes (5) adjustable height, magnetic pins, which can be used to provide a consistent component placement plane. This tool also reduces the amount of time required for changeover. *May need to order multiple kits depending on PCB size."
Part Number
Description
Foam Finger Board Support Unit
Details
The foam finger support unit includes a foam finger block which can be placed in the machine to support the board during component population. *May need to order multiple units, as well additional magnetic pins, based on PCB size and component density.
Part Number
Description
Magnetic Pins for Board Support
Details
Individual board support pins to provide flexible positioning under the placement area during set up.
Part Number
Installation Kits
Description
Details
Part Number
Description
Platform Installation and Set Up Kit
Details
This kit includes the basic tools required to install and/or move a Genesis Platform machine. Kit includes the following:
- Ratchet
- Sockets
- Precision level
- Spanner wrench
- Combination wrench
One kit per site is recommended.
Part Number
Description
Platform Installation & Alignment Kit
Details
This kit consists of the tools required to install and prepare a machine for production, including the machine aligners which are used to accurately finalize the machine's location and alignment. The kit includes:
- Additional sockets
- Torque wrenches
- Feeler gauges
- Additional ratchets
- Grease gun
- Dial indicator
- Combination and open end wrenches
- Ratchet and socket adapters
- Hex bits
- Y-axis tach fixture
- Machine aligner
One kit per site is recommended.
Part Number
Calibration Kits
Description
Details
Part Number
Description
2-4 Beam Platform Portable Cal. Kit
Details
An easy to use, portable calibration kit for use with 2-4 beam platform machines. The kit can easily be moved from machine to machine and includes a protective storage case. Note: The purchase of an apppropriate additional nozzle kit is required in order to run calibration. One kit per line is recommended.
Part Number
Description
Optical Feeder Calibration Fixture
Details
This kit allows for accurate verification of 8mm and 12mm feeder pick location for small chip and 0201 applications. The slot provides full access to the sides and top of the feeder, allowing any feeder type to be calibrated. The fixture includes an optical scope, Micrometer X-Y positioning system, and a precision calibration jig.
Part Number
Description
30-Spindle Head Nozzle Kit
Details
The 30-Spindle Head Nozzle Kit includes thirty 3260 (.340) compliant tip nozzles, which are used in conjunction with the Portable Calibration Kit, in order run machine calibration.
Part Number
Description
Spindle Replacement Calibration Fixture
Details
This device is a single spindle calibration tool which resides in the nozzle changer, and can be used to calibrate an individual spindle after replacement.
Part Number
Trim Kits
Description
Details
Part Number
Description
Platform Precision Trim & Measuring Kit
Details
This kit is used as part of the complete machine calibration process and is used to verify the placement locations, and adjust the final placements to meet final accuracy specs. This kit includes a glass slug board,calibration set up tools, and a protective case. Requires the purchase of an additional glass slug kit. One kit per site is recommended.
Part Number
Description
Glass Slug Calibration Kit, Add On
Details
This kit is used in conjunction with the Platform Precision Trim and Measuring kit. This kit consists of precision glass devices which can be used for final calibration and trim, and includes enough material to trim a single, Single-Beam, Dual-Beam or Quad-Beam machine. One kit per site is recommended.
Part Number
Description
Trim Kit, 0201 Live Parts
Details
This kit is used as part of the complete machine calibration process to ensure the highest level of placement accuracy. This kit is used to trim the Narrow Field of View Camera (NFOV) on the 30-Spindle head. Kit includes placement board, 0201 trim components, and set up tools. Requires the additional purchase of Lightning 0201 nozzle kit. One kit per site is recommended.
Part Number
Description
30-Spindle 0201 Nozzle Calibration Kit
Details
The 0201 Nozzle Kit consists of thirty (30) 3021 (0201) ceramic blade tip compliant nozzles, which are used in conjunction with the Portable Calibration Kit in order run machine calibration 1 per site is recommended for 1-beam machines. 2 per site is recommended or 2-4 Beam machines.
Part Number
Description
0201 Trim Component Kit
Details
Additional 0201 components for use in 0201 Live Component Trim

定制工具

隐藏式切换

您的内容放在这里。在行内或在模块内容设置中编辑或删除此文本。您还可以在模块“设计”设置中对这些内容的各个方面进行样式设计,甚至可以在模块“高级”设置中对这些文字应用自定义 CSS(层叠样式表)。

定制工具



Part Number
ion Feeders
Description
Part Number
Description
8MM DL ION TAPE FEEDER
Part Number
Description
12MM SL ION TAPE FEEDER
Part Number
Description
16MM SL ION TAPE FEEDER
Part Number
ion Feeder Reel Holders
Description
Part Number
Description
8MM DL 7" ION DUAL REEL HOLDER
Part Number
Description
8MM DL 7-13" ION SINGLE REEL HOLDER
Part Number
Description
12/16MM SL 7-15" ION SINGLE REEL HOLDER
Part Number
ion Feeder Baskets
Description
Part Number
Description
Ion Feeder Basket
Part Number
Description
Basket Pins and dividers
Part Number
Gold Feeders
Description
Part Number
Description
8MM HP GOLD PLUS SPLICEABLE TAPE FEEDER
Part Number
Description
8MM HP DUAL LANE-60 GOLD PLUS, 7" - 13"
Part Number
Description
8MM HIGH PERFORMANCE DL-60 GOLD PLUS
Part Number
Description
12MM HP GOLD PLUS SPLICEABLE TAPE FEEDER
Part Number
Description
16MM HP GOLD SPLICEABLE TAPE FEEDER
Part Number
Description
24MM HP GOLD SPLICEABLE TAPE FEEDER
Part Number
Description
32MM HP GOLD SPLICEABLE TAPE FEEDER
Part Number
Description
44MM HP GOLD SPLICEABLE TAPE FEEDER
Part Number
Description
56MM HP GOLD SPLICEABLE TAPE FEEDER
Part Number
Description
72MM HP GOLD SPLICEABLE TAPE FEEDER
Part Number
Description
88MM HP GOLD SPLICEABLE TAPE FEEDER
Part Number
Feeder Storage
Description
Part Number
Description
Feeder Transfer Cart
Part Number
Description
Feeder Storage Table
Part Number
Description
Feeder Storage Rack
Part Number
Single-Feeder Setup Stations
Description
Part Number
Description
SINGLE FDR INDEX STATION, NARROW
Part Number
Description
SINGLE FEEDER INDEX STATION

通孔零部件

为您的 Generation 8™、Generation 88™、Generation 88HT™ 和 Generation 88HTi™ 径向、轴向和跳线平台购置环球仪器正品零部件。

径向零部件

隐藏式切换

您的内容放在这里。在行内或在模块内容设置中编辑或删除此文本。您还可以在模块“设计”设置中对这些内容的各个方面进行样式设计,甚至可以在模块“高级”设置中对这些文字应用自定义 CSS(层叠样式表)。

径向贴装头工具



Part Number
G BLOCK
Description
Quantity
Part Number
Description
RPK,RL DUAL INSERT TOOLING
Quantity
Part Number
Description
PIN
Quantity
2
Part Number
Description
SPRING,COMPRESSION
Quantity
4
Part Number
Description
GUIDE JAW
Quantity
1
Part Number
Description
CLAMP, LH SINGLE
Quantity
1
Part Number
Description
CLAMP, RH DOUBLE
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
RPK, RL SINGLE INSERT TOOLING
Quantity
Part Number
Description
PIN
Quantity
2
Part Number
Description
SPRING,COMPRESSION
Quantity
4
Part Number
Description
GUIDE, JAW
Quantity
1
Part Number
Description
CLAMP, 2.5 RH
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
CLAMP, LH SINGLE
Quantity
1
Part Number
Description
RPK, RL SM TRIPLE INSERT TOOLING
Quantity
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
PIN
Quantity
2
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
GUIDE JAW
Quantity
1
Part Number
Description
CLAMP, RH DUAL
Quantity
1
Part Number
Description
CLAMP, DUAL
Quantity
1
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
RPK, RL LG TRIPLE INSERT TOOLING
Quantity
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
PIN
Quantity
2
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
GUIDE JAW, 5/7.5/10 SERRATED
Quantity
1
Part Number
Description
CLAMP, RH DUAL
Quantity
1
Part Number
Description
CLAMP, LH DUAL
Quantity
1
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
INSERT, PAD PUSHER
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLACK)
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLUE)
Quantity
1
Part Number
Description
RPK, RL SINGLE INSERT TOOLING
Quantity
Part Number
Description
PIN
Quantity
2
Part Number
Description
SPRING,COMPRESSION
Quantity
4
Part Number
Description
GUIDE JAW, 2.5
Quantity
1
Part Number
Description
CLAMP, 2.5 RH
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
CLAMP, LH SINGLE
Quantity
1
Part Number
Description
MSHCS M2 X 10MM
Quantity
5
Part Number
Description
RPK, RL DUAL INSERT TOOLING
Quantity
Part Number
Description
SPRING,COMPRESSION
Quantity
4
Part Number
Description
GUIDE JAW, 2.5/5.0
Quantity
1
Part Number
Description
CLAMP, LH SINGLE
Quantity
1
Part Number
Description
CLAMP, RH DUAL
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
MSHCS M2 X 10MM
Quantity
5
Part Number
Description
RPK, RL SM TRIPLE INSERT TOOLING
Quantity
Part Number
Description
PIN
Quantity
2
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
GUIDE, QUAD JAW TALL
Quantity
1
Part Number
Description
CLAMP, DL JAW (13MM)
Quantity
1
Part Number
Description
CLAMP, LH DUAL
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
MSHCS M2 X 10MM
Quantity
5
Part Number
Description
RPK, LG TRIPLE INSERT TOOLINGG
Quantity
Part Number
Description
PIN
Quantity
2
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
GUIDE JAW, 5/7.5/10
Quantity
1
Part Number
Description
CLAMP, DL JAW (13MM)
Quantity
1
Part Number
Description
CLAMP LH DUAL
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
INSERT, PAD PUSHER
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLACK)
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLUE)
Quantity
1
Part Number
Description
MSHCS M2 X 10MM
Quantity
5
Part Number
Description
RPK, QUAD INSERT TOOLING
Quantity
Part Number
Description
PIN
Quantity
2
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
JAW, QUAD SPAN GUIDE
Quantity
1
Part Number
Description
CLAMP, RH TRIPLE
Quantity
1
Part Number
Description
CLAMP LH DUAL
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
INSERT, PAD PUSHER
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLACK)
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLUE)
Quantity
1
Part Number
Description
MSHCS M2 X 10MM
Quantity
5
Part Number
Description
RPK,RL DUAL INSERT TOOLING
Quantity
Part Number
Description
MSDP 1.5MM X 8MM
Quantity
2
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
SPRING,COMPRESSION
Quantity
4
Part Number
Description
GUIDE JAW, 2.5/5.0
Quantity
1
Part Number
Description
CLAMP, LH SINGLE
Quantity
1
Part Number
Description
CLAMP, RH DUAL
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
INSERT, PAD PUSHER
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLACK)
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLUE)
Quantity
1
Part Number
Description
Cylindrical Bumper
Quantity
2
Part Number
Description
RPK, RL SINGLE INSERT TOOLING
Quantity
Part Number
Description
MSDP 1.5MM X 8MM
Quantity
2
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
GUIDE JAW, 2.5
Quantity
1
Part Number
Description
CLAMP, 2.5 RH
Quantity
1
Part Number
Description
CLAMP, LH SINGLE
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
INSERT, PAD PUSHER
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLACK)
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLUE)
Quantity
1
Part Number
Description
Cylindrical Bumper
Quantity
2
Part Number
Description
SPRING,COMPRESSION
Quantity
4
Part Number
Description
RPK, RL SM TRIPLE INSERT TOOLING
Quantity
Part Number
Description
MSDP 1.5MM X 8MM
Quantity
2
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
GUIDE, QUAD JAW TALL
Quantity
1
Part Number
Description
CLAMP, DL JAW (13MM)
Quantity
1
Part Number
Description
CLAMP, LH DUAL
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
INSERT, PAD PUSHER
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLACK)
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLUE)
Quantity
1
Part Number
Description
Cylindrical Bumper
Quantity
2
Part Number
Description
RPK, LG TRIPLE INSERT TOOLING
Quantity
Part Number
Description
MSDP 1.5MM X 8MM
Quantity
2
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
GUIDE JAW, 5/7.5/10
Quantity
1
Part Number
Description
CLAMP, DL JAW (13MM)
Quantity
1
Part Number
Description
CLAMP LH DUAL
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
INSERT, PAD PUSHER
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLACK)
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLUE)
Quantity
1
Part Number
Description
Cylindrical Bumper
Quantity
2
Part Number
Description
RPK, QUAD INSERT TOOLING
Quantity
Part Number
Description
MSDP 1.5MM X 8MM
Quantity
2
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
JAW, QUAD SPAN GUIDE
Quantity
1
Part Number
Description
CLAMP, RH TRIPLE
Quantity
1
Part Number
Description
CLAMP LH DUAL
Quantity
1
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SPRING, COMPRESSION
Quantity
4
Part Number
Description
SLIDE
Quantity
1
Part Number
Description
INSERT, PAD PUSHER
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLACK)
Quantity
1
Part Number
Description
INSERT, PAD PUSHER (BLUE)
Quantity
1
Part Number
Description
Cylindrical Bumper
Quantity
2
隐藏式切换

您的内容放在这里。在行内或在模块内容设置中编辑或删除此文本。您还可以在模块“设计”设置中对这些内容的各个方面进行样式设计,甚至可以在模块“高级”设置中对这些文字应用自定义 CSS(层叠样式表)。

径向剪脚器工具



Part Number
G BLOCK
Description
Quantity
Part Number
Description
RPK, CLINCH N LONG 5/7.5/10
Quantity
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
PIN
Quantity
2
Part Number
Description
PIN
Quantity
2
Part Number
Description
TUBING ASSY
Quantity
1
Part Number
Description
CUT/FORM, INTERIOR
Quantity
2
Part Number
Description
CUT/FORM, EXTERIOR
Quantity
4
Part Number
Description
ANVIL, INTERIOR
Quantity
2
Part Number
Description
ANVIL, EXTERIOR
Quantity
4
Part Number
Description
CUT/FORM, EXTERIOR 90 LLL
Quantity
4
Part Number
Description
ANVIL, EXTERIOR 90 LLL
Quantity
4
Part Number
Description
SSS 4-40 X 5/32 LG
Quantity
3
Part Number
Description
CABLE,CONTINUITY
Quantity
2
Part Number
Description
ECCENTRIC, SS, INSULATED
Quantity
2
Part Number
Description
RPK, RL DUAL CLINCH N STD
Quantity
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
PIN
Quantity
2
Part Number
Description
PIN
Quantity
2
Part Number
Description
CABLE,CONTINUITY
Quantity
2
Part Number
Description
TUBING ASSY
Quantity
1
Part Number
Description
SDP 1/8 X 7/8
Quantity
2
Part Number
Description
SSS 4-40 X 5/32 LG
Quantity
3
Part Number
Description
ECCENTRIC, SS, INSULATED
Quantity
2
Part Number
Description
CUTTER/FORMER STD N-POS 2
Quantity
3
Part Number
Description
CUTTER/FORMER STD N-POS 1/3
Quantity
6
Part Number
Description
ANVIL, STD N- POS 2
Quantity
3
Part Number
Description
ANVIL, STD N- POS 1/3
Quantity
6
Part Number
Description
RPK, RL DUAL CLINCH N LONG
Quantity
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
PIN
Quantity
2
Part Number
Description
ECCENTRIC, SS, INSULATED
Quantity
2
Part Number
Description
PIN
Quantity
2
Part Number
Description
CUT/FORM, INTERIOR
Quantity
3
Part Number
Description
CUT/FORM, EXTERIOR
Quantity
3
Part Number
Description
ANVIL, INTERIOR
Quantity
6
Part Number
Description
ANVIL, EXTERIOR
Quantity
6
Part Number
Description
CABLE,CONTINUITY
Quantity
2
Part Number
Description
TUBING ASSY
Quantity
1
Part Number
Description
SDP 1/8 X 7/8
Quantity
2
Part Number
Description
SSS 4-40 X 5/32 LG
Quantity
3
Part Number
Description
RPK,RL T CLINCH
Quantity
Part Number
Description
SPRING, COMPRESSION
Quantity
2
Part Number
Description
SPRING, COMPRESSION
Quantity
2
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
ANVIL, VSL
Quantity
4
Part Number
Description
CUTTER/FORMER, VSL
Quantity
4
Part Number
Description
ECCENTRIC, SS, INSULATED
Quantity
2
Part Number
Description
CENTER VSL CUTTER/FORMER ASSY
Quantity
3
Part Number
Description
CABLE,CONTINUITY
Quantity
2
Part Number
Description
TUBING ASSY
Quantity
1
Part Number
Description
SHCS 4-40 X 1/4
Quantity
5
Part Number
Description
SSSCPP 6-32 X 1/4
Quantity
5
Part Number
Description
SSSFP 1/4-28 X 1/4"
Quantity
5
Part Number
Description
SSSCNP 4-40 X 3/16
Quantity
5
Part Number
Description
SDP 1/8 X 1/2
Quantity
5
Part Number
Description
SPRG PIN .062 X .500
Quantity
5
Part Number
Description
SSS 4-40 X 5/32 LG
Quantity
4
Part Number
Description
RPK, RL SM TRIPLE CLINCH N STD
Quantity
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
PIN
Quantity
2
Part Number
Description
PIN
Quantity
2
Part Number
Description
TUBING ASSY
Quantity
1
Part Number
Description
SDP 1/8 X 7/8
Quantity
2
Part Number
Description
ECCENTRIC, SS, INSULATED
Quantity
2
Part Number
Description
SSS 4-40 X 5/32 LG
Quantity
3
Part Number
Description
CUTTER/FORMER STD N-POS 4
Quantity
3
Part Number
Description
CUTTER/FORMER STD N-POS 2
Quantity
3
Part Number
Description
CUTTER/FORMER STD N-POS 1/3
Quantity
6
Part Number
Description
ANVIL, STD N- POS 2
Quantity
3
Part Number
Description
ANVIL, STD N- POS 1/3
Quantity
6
Part Number
Description
ANVIL, STD N- POS 4
Quantity
3
Part Number
Description
CABLE,CONTINUITY
Quantity
2
Part Number
Description
RPK, RL SM TRIPLE CLINCH N LONG
Quantity
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
PIN
Quantity
2
Part Number
Description
PIN
Quantity
2
Part Number
Description
TUBING ASSY
Quantity
1
Part Number
Description
SDP 1/8 X 7/8
Quantity
2
Part Number
Description
ECCENTRIC, SS, INSULATED
Quantity
2
Part Number
Description
CUT/FORM, EXTERIOR 90 LLL
Quantity
3
Part Number
Description
ANVIL, EXTERIOR 90 LLL
Quantity
3
Part Number
Description
ANVIL, EXTERIOR
Quantity
6
Part Number
Description
ANVIL, INTERIOR
Quantity
3
Part Number
Description
CUTTER, MODIFIED EXTERIOR
Quantity
6
Part Number
Description
CUT/FORM, INTERIOR
Quantity
3
Part Number
Description
SSS 4-40 X 5/32 LG
Quantity
3
Part Number
Description
CABLE,CONTINUITY
Quantity
2
Part Number
Description
RPK, CLINCH N STD 5/7.5/10
Quantity
Part Number
Description
SPRING, COMPRESSION
Quantity
1
Part Number
Description
PIN
Quantity
2
Part Number
Description
PIN
Quantity
2
Part Number
Description
TUBING ASSY
Quantity
1
Part Number
Description
CUTTER/FORMER STD N-POS 4
Quantity
4
Part Number
Description
CUTTER/FORMER STD N-POS 1/3
Quantity
4
Part Number
Description
CUTTER/FORMER STD N-POS 2
Quantity
2
Part Number
Description
ANVIL, STD N- POS 2
Quantity
2
Part Number
Description
ANVIL, STD N- POS 1/3
Quantity
4
Part Number
Description
ANVIL, STD N- POS 4
Quantity
4
Part Number
Description
SSS 4-40 X 5/32 LG
Quantity
3
Part Number
Description
CABLE,CONTINUITY
Quantity
